Gigabyte A520M S2H Ultra Durable AMD AM4 ATX Motherboard
৳ 0
- Model: Gigabyte A520M S2H Ultra Durable
- Supports 3rd Gen AMD Ryzen Processors
- Smart Fan 5 Features
- Ultra-Fast NVMe PCIe 3.0 x4 M.2
- 4+3 Phases Pure Digital VRM Solution
Call For Price
Specification:
Gigabyte A520M S2H Motherboard
| Basic Information | |
| Supported CPU | AMD Socket AM4, support for 3rd Generation AMD Ryzen processors/ 3rd Generation AMD Ryzen with Radeon Graphics processors |
| Chipset | AMD A520 |
| BIOS | 1 x 128 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Form Factor | Micro ATX Form Factor; 24.4cm x 20.5cm |
| Expansion Slots | |
| PCI | CPU: 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 Chipset: 2 x PCI Express x1 slots, supporting PCIe 3.0 |
| M.2 Socket | 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support) |
| Memory | |
| Type | Dual channel memory architecture |
| Slots | 2 x DDR4 DIMM |
| Supported Memory | 3rd Gen AMD Ryzen Processors: Support for DDR4 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules 3rd Gen AMD Ryzen with Radeon Graphics processors: Support for DDR4 5000(O.C.) / 4866(O.C.) / 4600(O.C.) / 4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules |
| Maximum Memory | 64 GB |
| Graphics | |
| Graphics | Integrated in the 3rd Generation AMD Ryzen with Radeon Graphics processors: D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz DVI-D port, of 1920×1200@60 Hz HDMI port, of 4096×2160@60 Hz |
| Max Shared Memory | 16 GB |
| Connector & Ports | |
| HDMI | 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz |
| USB (s) | CPU: 4 x USB 3.2 Gen 1 ports on the back panel Chipset: 2 x USB 3.2 Gen 1 ports available through the internal USB header 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers) |
| LAN Port (s) | Realtek GbE LAN chip (1000 Mbit/100 Mbit) |
| Supported Storage | CPU: 1 x M.2 connector (Socket 3, M key, type 2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support) Chipset: 4 x SATA 6Gb/s connectors Support for RAID 0, RAID 1, and RAID 10 |
| Audio | Realtek ALC887 codec High Definition Audio 2/4/5.1/7.1-channel |
| Internal I/O Ports | 24-pin ATX main power connector 8-pin ATX 12V power connector CPU fan header 2 x system fan headers addressable LED strip header RGB LED strip header 1M.2 Socket 3 connector 4 x SATA 6Gb/s connectors front panel header front panel audio header USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only) serial port header speaker header 1chassis intrusion header Clear CMOS jumper |
| D-Sub (s) | D-Sub port, supporting a maximum resolution of 1920×1200@60 Hz |
| DVI-D (s) | DVI-D port, supporting a maximum resolution of 1920×1200@60 Hz |
| Warranty Information | |
| Manufacturing Warranty | 03 years |
| Others | |
| Special Features | Support for APP Center @BIOS EasyTune Fast Boot Game Boost ON/OFF Charge RGB Fusion Smart Backup System Information Viewer Support for Q-Flash Plus Q-Flash Xpress Install Q-Flash Xpress Install |
| Bundled Software | Support for Windows 10 64-bit |
Description :
Gigabyte A520M S2H Motherboard Overview
GIGABYTE UD series motherboards use a 4+3 phases pure digital PWM + Low RDS(on) MOSFETs design to support the 3rd Gen AMD Ryzen CPUs by offering incredible precision in delivering power to the motherboard’s most power-hungry and energy-sensitive components as well as delivering enhanced system performance and ultimate hardware scalability. Motherboards are focused on delivering M.2 technology to enthusiasts who want to maximize their system’s potential. Realtek 8118 LAN is a high performance and friendly network chip for gaming players with automatic bandwidth allocation to ensure the highest network priority of the game or application. It can provide users the most comprehensive features and the fastest and smoothest Internet experience.
| Brand | Gigabyte |
|---|---|
| Processor Brand | AMD |
| Generation | 3rd Gen |
| RAM Type | DDR4 |
| Bus Speed | 2133 MHz, 2400 MHz, 2666 MHz, 3200 MHz, 3600 MHz |
| RAM Slot | 2 |
| HDMI Port | YES |
| M.2/NVMe Expention slot | 1 |
What is the price of Gigabyte A520M S2H Ultra Durable AMD AM4 ATX Motherboard in Bangladesh?
The latest price of Gigabyte A520M S2H Ultra Durable AMD AM4 ATX Motherboard in Bangladesh is .00৳. You can buy the Gigabyte A520M S2H Ultra Durable AMD AM4 ATX Motherboard at best price from our website or visit any of our showrooms.
